Deep learning for accurate, affordable and accessible eye-tracking

Shreshth Saxena (saxens17@mcmaster.ca)
Supervised by Dr. Lauren Fink and Dr. Elke Lange

Eye Movements

Eye Movements

retina rods and cones
Source: "Cognition / Daniel Reisberg"

Eye Movements

Visual Attention

Reading, scene viewing, art/film perception, visual search etc.

Human Computer Interaction

Interface design, driving, aviation, marketing/advertising etc.

Memory & Ageing

The obligatory effects of memory on eye movements, Ryan et al. (2007)

Auditory Attention

Fink et al. (2018), Lange et al. (2017), Maroti et al. (2017)

Eye Tracking

Eye Tracking (Hardware focussed)

Desktop mounted

SR Research Eyelink 1000

Head mounted

SR Research Eyelink II
Pupil core glasses

Eye Tracking(Software focussed)

Source: Apple continuity camera
Gaze360: Kellnhofer et al. (2019)
RT_Gene: Fischer et al. (2018)
Webgazer: Papoutsaki et al. (2016)
Eye Tracking(Software focussed)

Eye Tracking(Software focussed)

Web browser based Deep learning based
Proprietary: Xlabs, LabVanced, Gorilla
Open-sourced: WebGazer, TurkerGaze 		MPIIGaze, RT-GENE, FAZE, ETHXGaze
Specialized tasks: web browsing behavior (WebGazer, Xlabs), Image saliency prediction (TurkerGaze) Developed for generalized gaze prediction
Low-order feature detection (susceptible to noise) Higher order feature learning (robust to noise)
Hardware specifications are a performance bottleneck Modular and actively being developed for better performance
Webgazer reported an error of 4.17˚ in online studies FAZE reported an error of 3.18˚ on GazeCapture dataset
Online webcam-based eye tracking in cognitive science: A first look, Semmelmann and Weigelt (2018) Appearance-based Gaze Estimation With Deep Learning: A Review and Benchmark, Cheng et al. (2021)
Deep learning based

Gudi et al. (2020)
Cheng et al. (2021)
Xhang et al. (2020)

Our study

Our study

MPIIGaze
Zhang et al. (2015)		 ETHXGaze
Zhang et al. (2020)		 FAZE
Park et al. (2019)
CNN architecture LeNet Resnet-50 DenseNet based Encoder-Decoder
Training dataset MPIIGaze ETHXGaze GazeCapture
Accuracy (MPIIGaze dataset) 6.3⁰ 4.8⁰ 3.06⁰
Inference speed ~12fps ~4fps ~1fps

Our study

N=65
(age btw 20-35; no glasses)
Pre-registration: https://osf.io/qh8kx

Online experiment

Calibration

Online experiment

Calibration

Screen calibration
Distance calibration
Fix-point calibration
Smooth pursuit calibration


Shreshth Saxena, Elke Lange, and Lauren Fink. 2022. Towards efficient calibration for webcam eye-tracking in online experiments. In 2022 Symposium on Eye Tracking Research and Applications (ETRA '22). Association for Computing Machinery, New York, NY, USA, Article 27, 1–7. https://doi.org/10.1145/3517031.3529645


Task battery

Fixation

MPIIGaze ETHXGaze FAZE
Accuracy 3.70°
(IQR: 2.74°-4.59°)		 3.40°
(IQR: 2.67°-4.13°)		 2.44°
(IQR: 1.86°-2.90°)
Root Mean Squared
(Precision)		 2.33°
(IQR: 1.88-2.75)		 1.80°
(IQR: 1.28°-2.29°)		 0.47°
(IQR: 0.29-0.64)
Standard Deviation
(Precision)		 2.96°
(IQR: 2.32°-3.57°)		 2.39°
(IQR: 1.70-2.98)		 1.63°
(IQR: 1.06° 2.07°)

Zone classification

Zone classification

Free viewing

Free viewing


MPIIGaze ETHXGaze FAZE
Fixation count 14
IQR: 12-18		 13
IQR: 10-15		 12
IQR: 11-13
Gaze entropy 0.40
IQR:0.38-0.44		 0.38
IQR: 0.35-0.41		 0.35
IQR: 0.33-0.37

Smooth pursuit

Blink detection

EAR RT_BENE
blinks/trial 6.9 (IQR: 6.3-7.2) 5.3 (IQR: 4.9-6)
blink latency 381 ms(IQR: 293-427 ms) 419 ms(IQR: 318-502 ms)
blink duration 403 ms(IQR: 383-424 ms) 212 ms(IQR : 157-243 ms)

Comparing with lab-based eye tracking

Ehinger et al. (2019) https://doi.org/10.7717/peerj.7086

Comparing with lab-based eye tracking



Task Measure Webcam results (model) Pupil Labs EyeLink
Fixation Accuracy 2.44° (FAZE) 0.82° 0.57°
Precision (RMS) 0.47° (FAZE) 0.119° 0.023°
Precision (STD) 1.63° (FAZE) 0.311° 0.193°
Smooth Pursuit Onset latency 0.267s (MPIIGaze) 0.245s 0.241s
Blink Detection Number of blinks 6.9 (EAR) 5.3 *7.1
Blink duration 0.212s (RT_BENE) *0.214s 0.190s

Conclusion

  • Eye-tracking task battery provided a comprehensive evaluation
  • Accuracy of 2.4° from best performing model
  • Better accuracy near the center of screen
  • High accuracy in classifying gaze to screen zones/regions
  • Can generate heatmaps and scanpaths similar to lab-based eye-tracking
  • Can accurately tracks gaze movement direction
  • FAZE performs best in all tasks but also is the most computationally expensive
  • Blink detection with appearance based methods is comparable to high resolution eye trackers

Conclusion

  • Deep learning improves eye tracking accuracy for online setups
  • It increases affordability, scalability and validity of studies
  • It requires less calibration, longer trials feasible
  • We create and release processing pipelines for 30Hz eye-tracking data
  • Limitations: Resolution, real-time application


Thank you for your attention

Acknowledgement: Max Planck institute for Empirical Aesthetics, Frankfurt, Germany
